3 Way Ball Valve are designed to switching, converging and diverging the flow direction of water, oil and gas (W.O.G). There are 2 different ports of 3 Way Ball Valve, “T” port and “L” port. The “L” port is used for switching flow direction, the valve connect 2 different flow channels that are vertical with each other. The “T” port is used for switching also converging and diverging the flow direction, its allow 3 channels connect together or two of them connect with each other to realize two.

Three-way ball valves can

• Cut of or shut off flow
• Switch flow between two different sources
• Combine the flow from two different sources
• Alternate flow between two different destinations
• Divert flow coming from one source to another destination
• Split flow coming from one source between two outgoing destinations

Applicable Standards:
- Ball Valve Design According to API6D, BS5351, ASME B16.34
- Face to face ASME B16.10, API6D
- End Flanges ASME B16.5/ASME B16.47
- Butt Welding ends ASME B16.25

-Fire Safety API6D, API6A

- Inspection and test API 598, API6D

Size Range:
- 2"~48"
Pressure Rating:
- ASME CL, 150, 300, 600
Temperature Range:
- -196°C~650°C
