Axial Flow Check Valve | Nozzle Check Valve | JONLOO

China check valve manufacturer JONLOO supplies Axial Nozzle Check Valve.The axial nozzle check valve is the preferred solution for preventing return flow or shocks on critical process equipment. Typically used on rotating devices and systems where low pressure loss, stable operation, and smooth dynamic behaviour is essential.

Tags:

• Check Valve
• Flanged Check Valve
• API Check Valve
• Stainless Steel Check Valve

Product Specifications:
1. Size: 2"~48" (DN50~DN1200).
2. Pressure: 150~2500LB (PN16 – PN420).
3. Material: Carbon Steel, Stainless Steel, Alloy Steel.

Technical Specification:
1. Design & Manufacture standard: API 6D, ASME B16.34.
2. Face to face dimension standard: ASME B16.10, API 6D
3. Flange standard: ASME B16.5, ASME B16.47.
4. Butt welded Ends: ASME B16.25.
5. Test & Inspect standard: API 598.

Product Feature:
1. Venturi port to reduce pressure drop.
2. Spring protection and no impact.
3. Low noise and lower water hammer damager.
4. Soft seal and second metal to metal seal to ensure fire safe.
5. Full series with lugs and support legs.
6. No outside leakage.

The axial nozzle check valve is the preferred solution for preventing return flow or shocks on critical process equipment. Typically used on rotating devices and systems where low pressure loss, stable operation, and smooth dynamic behaviour is essential.

Often it does not become evident until a plant is operating that the selected non-return valves slam heavily and produce high pressure peaks that damage surrounding equipment.

The inherent non-slam characteristic of this axial nozzle check valve is achieved because the valve reacts so quickly to flow changes, ensuring no reverse flow or shocks occur within the piping system.
